Why Contractors Upgrade to the EE10P Compact Digger

• Extended 1.7m Trenching Geometry: Delivering a deep 1,700 mm digging depth and 3,050 mm maximum reach, the EE10P enables utility installers and drainage contractors to reach municipal grade depths without mobilizing larger, costlier iron.
• Short-Chassis Agility (2,200mm Overall Length): Engineered with an ultra-compact 2,200 mm transport length, 2,000 mm height, and 930 mm stance, it navigates narrow gates and loads crossways or in tandem on standard utility trailers with zero wasted deck space.
• Wide-Angle Bilateral Boom Swing: Offers 60° left swing (400 mm offset) and 45° right swing (320 mm offset) alongside a short 660 mm tail radius, allowing direct trenching flush against masonry walls, property barriers, and trees.
• Dual Fuel Compliance (EPA 4 & Euro 5): Power your fleet with either the snappy, easy-starting RATO R420 gasoline engine (9.9 kW @ 3600 rpm) or heavy-lugging KOOP KD192FE single-cylinder diesel engines (up to 32 N·m torque) built for uninterrupted daily operation.

✔ Deep Utility & Drain Trenching: Reaching 1,700 mm deep with 9 kN bucket tear-out power, the EE10P rapidly excavates residential stormwater channels, water pipes, and foundation perimeters in fewer passes.

✔ Fast 3.0 km/h Ground Tracking: High-torque hydraulic track drives enable 3.0 km/h jobsite transit and a 15 kN traction pull, accelerating backfilling passes and speeding up cross-site movements.

✔ Productive 400mm Wide Bucket: Standard equipment includes a wide 400 mm digging bucket, maximizing volume per scoop to cut excavation cycle times during trenching and truck loading.

✔ Compact 2.2m Hauling Dimensions: At just 2.2 meters in transport length and 1,000 kg operating weight, hire fleets can fit two units on a medium plant trailer, dramatically trimming contractor dispatch costs.
