video

EE06 Mini Excavator

Factory Direct
Training on Arrival
One-year warranty

Operation weight: 600Kg

Bucket capacity: 0.015cbm

Rated power: 6.8Kw

Product Introduction

EE06 Micro Excavator | 0.6-Ton Doorway-Pass Compact Digger with Gas & Diesel Power

600kg Operating Mass | 690mm Gate-Pass Width | RATO Gas / KOOP Diesel (EPA/Euro 5) | 1,400mm Dig Depth

Why Jobsite Contractors Rely on the EE06 Micro Digger

  • True Single-Doorway Clearance (690mm): Measuring only 690 mm across the tracks and 1,657 mm in transport height, the EE06 negotiates standard residential garden gates, interior doorways, and narrow side alleys without dismantling gateposts or fences.
  • Turf-Safe Footprint (14.6 kPa): Weighing just 600 kg on 150 mm rubber tracks, the machine exerts a feather-light ground pressure of 14.6 kPa, allowing operators to cross manicured estate lawns and sensitive indoor floor tiles without leaving ruts or surface cracks.
  • High-Deflection Swing Boom (75° Left / 57° Right): Features an expansive independent boom articulation range (548 mm left offset / 417 mm right offset), providing pinpoint boundary trenching right against structural walls, hedge borders, and property limits.
  • Dual-Spec Engine Versatility: Available with either the high-rpm RATO R420 gasoline powerplant (9.9 kW, EPA 4/Euro 5) for quick throttle response or the air-cooled KOOP KD192FE diesel engine for high-torque fuel thrift on continuous site work.
ModelEE06
Operating Weight600 kg (0.6 Ton)
Chassis Overall Width690 mm
Bucket Capacity / Breakout Force0.02 m³ / 7.45 kN
Engine OptionsRATO R420 (Gasoline) / KOOP KD192FE (Diesel)
Max. Digging Depth1400 mm (1.4 m)
⬇️ View Full Technical Parameters & Dimensions ⬇️
Specification
Operating Weight600 kg
Bucket Capacity0.02 m³
Fuel Tank Capacity5 L
Engine
Engine Modela. KOOP KD192FE (China Stage II)
                       b. KOOP KD192FE-E5 (EURO 5)
                       c. RATO R420 (EURO 5 / EPA 4)
Displacementa 0.499, b 0.499, c 0.42 L
Company Profile

Eurtrol — Your Trusted Partner in Heavy Machinery

Established in 2010, Eurtrol is a leading manufacturer specializing in high-performance mini excavators, forklifts, and drilling rigs. With a 12,000㎡ facility and a 185-strong expert team, we deliver durable, professional-grade equipment to clients in over 120 countries, empowering success across construction, landscaping, and agriculture sectors worldwide.
